Quick Details

  • Type: Automatic Door Operators
  • Place of Origin: Jiangxi, China (Mainland)
  • Brand Name: BISEN
  • Model Number: BS-PK03
  • Item name: Automatic Swing Door Opener : BS-PK03
  • Motor Power: 12VDC /24VDC 40W*2
  • Current: 2A
  • Rotational Speed: 3200rpm
  • Max single-leaf length: up to 3/4M
  • Protection calss: IP55
  • Rod's running speed: 1.6cm/s
  • Rod's max travel: 300/400mm
  • Max single-leaf weight: 300kg
  • Gate material: wood, steel, aluminum, vinyl,chain link,and so on

Packaging & Delivery

Packaging Details carton box per set: 88*43*19cm
10 sets per wooden pallet: 80*96*108cm
Delivery Time Shipped in 10 days after payment

BS PK03  Electric  Automatic Swing Door Opener  With CE

Features:



Safe: BS-PK Swing Gate opener meets the highest standard in safety.

Reliable:Electro-mechanical automated gate opener is time-tested design.

Convenient: Quick, Safe and Secure Manual Releas-A release key that can be used should the power fail or the backup battery is not charged.



BS-PK03 control download manual of install and use(For Control).

1. In case of power failure,release the clutch easily,and operate the gate manually.

2 .Stop acting when gate meets with obstacle.



Item name

BS-PK03

Motor Power:

12VDC/24VDC 40W*2

Current:

2A

Rotational Speed

3200rpm

Rod’s running speed

1.6cm/s

Ros’a max travel

300/400mm

Max single -leaf length

up to 3/4m

Max Single -leaf weight

300Kg

Gate Materials

wood, steel aluminum,vinyl chaina link, and more

Environment temperature

-10℃~+50℃

Protection class

IP55

Cycles per Hour

Continuouse Duty, approximately 75





Company Information

Bisen Smart Access co., Ltd. was established in 1999. This is the biggest professional manufacturer for automatic access equipment. Bisen has been awarded more than 200 patents in China and Europe.



In 2015, Bisen built the new factory and invested in new facilities , Steel plate flexible product line, Welding Robots, Automatic spraying equipment, to improve the quality control and capacity.



BAISHENG GATE & DOOR AUTOMATION CO.,LTD   Located in Nanchang Minying Science & Technology Park, Nanchang city, China. The production area is 40,000 square metres.


We are the biggest Professional manufacturer for Gate and Door Automatic Operators in China. More than 50 experienced engineers are engaged in R & D,and more than 500 employees are working in manufacture and service.


We can provide quality ODM/OEM service for customers in the world.BISEN SMART ACCESS CO.,LTD. was established in 1999, Located in Nanchang Minying Science & Technology Park, Nanchang city, China. The production area is 40,000 square metres.

Our main products:Auto-barrier gate,Garage door opener,Roll up door opener, Swing gate opener, Sliding gate opener, Industrial sectional door opener,Anti-terrorism Road Blocker,Hydraulic Bollard,Pedestrian Gate,Entrance control system etc.

1.Our factory covers more than30,000 square meter .

2.We specialize in Automatic door& gate opener since 1998.

3.Our main products are traffic barrier,garage door opener,swing gate operator,
Sliding gate opener,industrial sectional door operator ,road blocker ,bollard and so on.

4.The certificate we got: CE,ISO9001:2008
5.We have formed 10 production lines.


6.Exhibition we attend:

a)The U.S. Guardrail Exhibition ,

b)Chinese Commodity Fair in Jordan ,

c)IDA Automatic Door Show ,

d) Italian Building Material Exhibition ,

e) Polish Building Materials Exhibition ,

f) The Canton Fair
7.Our big markets: main customers are from Europe ,the USA,Canada,Russia,Mexico ,middle east ,South Africa etc.
8.ODM/OEM service is welcome.

Packaging & Shipping

1.Standard export carton or wooden case.

2.Packaging Details:Carton box with pallet.

3.Delivery Detail:5-6 Working Days after received payment.

4.Packaging:1 set packed as 1 carton;10 sets packed as 1 pallet.

5.Shipping:If you do not have forwarder,we can arrange  shipping by express,air and sea.



Exhibitions

Certifications

Our Services

1. OEM Manufacturing welcome: Product, Package...

2. MOQ: 1 piece

3. Car Parking System Warranty:1 year

4. We will reply you for your inquiry in 24 hours.

5.Warranty:electronic parts:1 year  mechanical parts: 2 years

We have our own overseas service department and professional technology team, can meet  different requirements of customers in the shortest time and supply the best service when you back home.

Putting customer first is our principle all the time!



FAQ

Trouble

Cause

Shooting

Motor can not work

1,No power supply

2,Break fuse

3,Surpass load

1,Check power supply

2,Change fuse

3,Check if any barrier on the track

Can open but can not close

1,Photocell is not connected properly

2,Photocell beam is block off

3,Photocell is broken

1,Connect the photocell

2,Clear out obstacle

3,Change a new device

Can open (close) but can not close (open)

1,Position of limit switch is not correct

2,Limit switch is damaged

1,Adjust position

2,Change limit switch

Can not locate accurately

1,Distance of limit switch is too large

2,Limit switch is wrong

3,Magnetic-stells

  position is wrong

1,Adjust position of limit switch

2,Change limit switch

3,Re-adjust the position

Release device is doesnt work

1,Operating handle is broken

2,Worm gears are jammed

1,Change the handle

2,Rotate the pinion

Push the OPEN button

 but the gate close

Whether +MOTOR- wires are

connected wrong

Connect correctly according to

 wiring diagram

Motor can turn but can not work

1,Compression spring of clutch is dead

2,Gear box is released

1,Change the spring

2,Couple the worm gear
